Saturday, May 21, 2011

270EX for Macro - improved version.

As mentioned in my previous post on using a single 270EX for macro, there were two issues that needed to be addressed. The two issues were:

1. shadow on the lower part of the subject
2. very dim catch light in subject's eyes.

In my opinion, these two issues were caused by the fact that the 270EX was too far out and as a result, the light would come down from a higher angle.

In this post, I will show you the solution. You will not believe how simple it is. I don't even need a ballhead anymore!

This animated gif will tell you everything you need to know!
270ex for macro upside down

New vs old method:

Left: 270EX upside down/belly up        Right: 270EX in normal position (upside up?:D)
270EX upside down vs old method
The 270EX was on an FMMB (Front Mounted Macro Bracket) mounted onto the front of the lens. This is extremely convenient for lenses with no IF (Internal Focus). The bracket and speedlight will move along when you zoom in/change magnification. (Edit: i still love my MT24 though and use this 270EX on FMMB as backup only)

If you are not sure how to make an FMMB, here are your alternatives:

1. Lens hood based flash holder.
2. Mount Ring / Tripod collar


I was playing with my 270EX, extending the head out, tilting it at different angles when the idea struck me - turn the 270EX upside down (belly up)!

As can be seen in the gif animation, at its lowest flash head position, it can handle the MPE65's working distance at 5X (1.6 inches). With this improved setup, now I can just tilt the 270EX's flash head to take care of different working distances/magnifications of the MPE65! Sweet! Now, if only the 270EX comes with focusing light as well like the MT24EX does! But you can't have the cake and eat it too though.

The MPE65's working distances at different magnification are as below:

1X - 4 inches; 2X - 2.5 inches, 3X - 2 inches; 4X - 1.7 inches; 5X - 1.6 inches

Sample images taken with this new setup. I used the same concave light tent diffuser that I use for the MT24EX.

270ex upside down on FMMB and MPE65 R0011092 copy

Blue tiger beetle (Neocollyris formasana?) with red socks.
blue tiger beetle with red socks Neocollyris formasana IMG_2892 copy

Grey ant,  Diacamma sp.
Diacamma sp. grey ant IMG_2946 copy

A female Bathippus sp.(?) jumping spider
female Bathippus sp. jumping spider IMG_2978 copy

A tiger beetle with an ant's head
tiger beetle with phoretic mite IMG_3010 copy

Check out this post for more macro rigs.


As an Amazon Associate I earn from qualifying purchases.

Monday, May 16, 2011

270EX for macro

By now, I am sure you are aware that many of my macro friends use single 270EX as their light source for macro. Just check out this post in case you missed that. It's been proven without any doubt that a single 270EX is just as good as twin flash.

Two of the easiest and most light weight ways of holding the 270EX in place are:

1. an FMMB (front mounted macro bracket).  More info about the FMMB here.

FMMB is great for lenses without IF (internal focus) and/or lenses without tripod collar/mount ring. Example: Tamron SP90, MPE65 (both SP90 and MPE65 extends out considerably) , and Nikon 105mm (no tripod collar?)

270EX on the FMMB, MPE65 and 40D. (Edit: this is the old method. New and improved method is here)
270ex on FMMB, MPE65 macro rig RIMG0985 copy
Yellow arrow shows that the oce3 cable is preventing the 270ex to be pointed any lower.

The angle between the two green arrows are more than 45 degrees, so the lighting is more like top lighting. A comparison to the MT24EX can be seen below, after a few sample shots.

Sample shots:

I used the same concave diffuser like this. More about that concave diffuser here.
concave diffuser RIMG0934 copy

Jumping spider. Noticeably much much dimmer catch lights in the jumper's eyes. I personally prefer it to be slightly stronger. I am guessing this is due to the higher light angle.
270ex on fmmb sample shot jumping spider IMG_1713 copy

Fly. Heavy shadow on the lower part of the fly. I am not too concerned about shadow below the subject, I am more concerned about shadow on the lower part of the subject. Again, i am sure this is due to the higher light angle.
270ex on fmmb sample shot, fly IMG_1739 copy

hover fly
270ex on fmmb sample shot hover fly IMG_1723 copy

270EX on FMMB versus MT24EX
270ex on FMMB vs mt24
Bigger image here.

The 270EX is just too far out and shines down from a higher angle, whereas the MT24EX flash heads are just on top of the front of the lens/filter, with lower angle too. (Compare the angles between the green lines). These  explain why we get dim catch lights on subject's eyes and the shadow on lower part of subject. I think I found the solution already and I will share it in my next posting.

Note: the shadow and dim catch light issues are more prominent in the MPE65's higher magnification range i.e 2x and above. At 1X, with a working distance of 4 inches (front of lens to subject), it should be okay.

(Edit: check out the new and improved method that solves the shadow and dim catch light problem)

For normal 1:1 macro lenses, this setup should still work well.

 2) Mount Ring/Tripod Collar

Almost no DIY required compared to the FMMB, but you will need to add in one or more extension tube(s) or teleconverter in order to be able to rotate the tripod collar/mount ring 180 degrees.

tripod collar or mount ring RIMG0125 copy
